VANGUARD ELECTRONICS, manufacturer of inductors, transformers, all kind of windings for tough applications in Defense, Aerospace, Avionics, Oil & Gas, Medical activities; is launching planar components, HILO series.

Planar structure is based on flattened magnetic cores with windings realized on pcbs which provide more embedded power (up to 100A, withstand voltage 500Vrms).

The advantages of this technology compared to conventional coils are: repeatability, high density of power, better efficiency, easier cooling, improved heat dissipation.

HILO series can meet space grade or high temperatures (up to 200°C) operations in option. Read more and download datasheet here.

For more information on Vanguard, its products or quotation please contact us at TriLight Microwave.

Microwave Systems offers the MS010620 multi-octave, high-power GaN amplifier designed to operate from 1 to 6 GHz. It is ideally suited for use in communications systems, radar systems, test instrumentation, broadband RF telemetry, point to point radio, and fiber optics applications.

This high-power GaN amplifier provides a saturated output power of 41 Watts with a small signal gain of over 55 dB, which can be controlled digitally. It features a built-in output power detector, high switching speeds, gain-temperature compensation, and high reliability and ruggedness. The amplifier is available in a hermetically sealed package that measures 6.62 x 3.08 x 0.93 inches with SMA Female connectors.

TriLight Microwave have this and several other models in stock. For further information or quotation, please contact us!

Evans Capacitors are a range of hybrid Wet Tantalum capacitors designed for high current operations in harsh conditions.

The novel technology allows for high capacitance beyond that available in standard wet tantalum technology, to operate at significant voltages and high currents to give high power capability, either in pulsed applications due to their low ESR, or hold up applications due to their combination of high capacitance and low ESR.

In addition the construction method and materials used allows for use in high temperature applications up to and beyond 200 deg C. One consideration is the lifetime of operation under these conditions, and Evans capacitors have been precisely tested and documented to offer extended lifetimes at high temperatures.

They come in 2 form factors,  the traditional radial (HyCap) wet tantalum package, and the circular ‘pill type’  (THQA-HT) package.

High Temperature HyCap Series Hybrid capacitors are designed for operation up to 200°C. HC-HT capacitors provide a full rated life of 2,000 hours at 200°C and HC2-HT capacitors are rated for 1,000 hours at 200°C.

THQA2-HT Series hybrid capacitors are suitable for operation up to 200°C. THQA2-HT Hybrid Capacitors are in the same form factor as the standard THQA2, with a life of 1,000 hours at 200°C or 2,000 hours at 175°C.

Both designs are ideal for applications that are mission critical, including defence and down hole Oil & Gas.
For more information regarding Evans and request for quotations please contact us at TriLight Microwave Europe.


Integra offers a high power pulsed avionics L-band module and a high efficiency, low input/output VSWR module. IGNP0912L1KW is a 50-ohm matched GaN-based high power pulsed pallet amplifier for L- band avionics systems operating over the instantaneous bandwidth of 0.960 – 1.215 GHz. This module supplies a minimum of 1000 W of peak pulse power, under the conditions of 2.5ms pulse width and 20% duty cycle. This module is ideal for Class AB operation with excellent thermal stability.

IGNP0912L1KW has a gain of 12.0 dB, frequency of 0.1 – 1.0GHz and a voltage of 28V. IGNP1214M1KW-GPS is a single-supply 50-ohm matched GaN-based pulsed power module for L-band radar systems, operating in the 1.20 – 1.40 GHz instantaneous frequency band. The module supplies a minimum of 1000 W of peak pulsed output power under the conditions of 300us pulse width and 10% duty cycle. The module contains bias sequencing and RF-activated gate biasing circuitry to simplify system integration. All units are 100% screened for large signal RF parameters.

Learn more about IGNP0912L1KW and IGNP1214M1KW-GPS and download the full datasheets here.

For more information or request for quotation please contact us at TriLight Microwave Europe.

During these unprecedented times, Trilight Microwave wanted to ensure continued supply of our components to all customers. We have completed due diligence with our suppliers and are happy to inform you that for the time being the supply of products on order, and future orders will be uninterrupted. This of course is subject to any future directions given by the Swedish government regarding the flow of goods in to and out of the country, and of any governments with jurisdiction at the point of manufacture.

Trilight have instigated social distancing in the office and appropriate cleaning methods are being employed in any shared areas in the office / warehouse. Where possible home working is now the norm to minimise personnel in the office, and travel has been minimised to only absolutely essential journeys.

If you would like added security in supply, Trilight offer stocking capabilities, ensuring the components will reside in Europe, and a fast turn around for customers. In addition, if you have future planned demand, Trilight will be able to investigate current stock levels for additional security of supply for you. Please contact your local Trilight employee for further information.

Passive Plus Inc. (PPI) has expanded its Broadband Capacitor line to include the industry’s smallest .010”x.005” Broadband part characterized for RF performance. The 01005BB104 (100nF) Broadband multilayer ceramic capacitor specifications:

For more information reg PPI or your capacitor needs, please contact TriLight Microwave.

CX Thin Films are a high quality thin Film manufacturing company with an enviable record of manufacturing Thin Film tiles in volume and to competitive pricing.

CX Thin Films have been manufacturing for the Microwave and Optical industries for more than 10 years and have built up a loyal customer base across the world.

Their capabilities include:

  • 100% Electrical/ Laser Part Test and Trim available with full mapping and Read and Record data
  • Photolithography- Patterning, Wet and Dry Etching
  • Nickel and Gold Plating
  • Dicing
  • RF and DC Sputtering
  • Repackaging
  • Die Handling: Semi-Automatic Tape to Waffle Pack Die Pickers
  • Tape and Reel, Waffle Pack, Gel Pack, Film Frame Die Handling
  • Singulation of Silicon, Alumina, Quartz, Beryllium Oxide, and Aluminum Nitride
  • Full in-house Design Capability
  • 100% Visual and DC Electrical Inspection per MIL-PRF-55342
  • Complete MIL-PRF-55342 Testing Capabilities
  • Element Evaluation per MIL-H-38534, Class H and K

For more information or request for quotation please contact TriLight Microwave.

You can download the CX Thin Films catalog here.

You can now download from below link the 2020 Passive Plus (PPI) catalog for High Q/Low ESR capacitors range.

If you would like a printed copy of the catalog sent to you or have any inquiries and questions reg PPI assortment please contact us at TriLight Microwave.

PPI Catalog 2020







Evans Capacitor Company, the 2018 SBA National Subcontractor of the year, has received $7 million in follow on orders from Northrop Grumman to produce high power capacitors.

Read more;

https://www.prweb.com/releases/evans_capacitor_company_awarded_contracts_totaling_7_million_for_capacitors_providing_dc_storage_for_state_of_the_art_airborne_radar/prweb16703255.htm#

For information on Evans Caps or request for quotation please contact TriLight Microwave.

PPI 1209 Broadband Resistors are specifically designed to operate at frequencies up to 67 GHz.  With special microwave laser-trimming used to ensure a tight tolerance at high frequencies, these Broadband Resistors are wire bondable, solderable, and can be used in a flip-chip configuration. Available in full or recessed pad.

Applications: Optical Transceiver Modules, Broadband Receiver, TOSA/ROSA, Broadband Test Equipment, Low Noise Amplifiers, MMIC Amplifiers, 5G

Markets: Opto-Electronics, Telecom, Broadband, Military, Satellite Communication

For more information please contact TriLight Microwave.

PPI – BB Resistors 1209
